ABOUT THIS PIVOT LOCK SET
The QS5504 Heavy Duty Pivot Lock Set is a robust locking solution designed for large and heavy pivot doors.
This product is a mixed-brand solution, combining compatible components from QS and CISA to achieve a reliable and practical pivot door locking system.
The combination is intentional, allowing the system to deliver both structural performance and reliable locking functionality.
This lock set is suitable for heavy duty applications where door weight, size, and durability are key considerations.
Pivot lock sets provide the locking function only and must be used together with a floor spring and pivot hardware to create a complete pivot door system.
The QS5504 is designed for doors up to 250kg.
⚠️ IMPORTANT – THIS IS NOT A COMPLETE PIVOT DOOR SYSTEM
This product is a lock set only.
To operate correctly, a pivot door requires:
• Floor spring (controls door movement)
• Pivot set (carries door weight)
• Lock set (this product)
• Cylinder (for key operation)
• Handles with escutcheons
👉 Without these components, the door will not function correctly.
🔄 MIXED BRAND EXPLANATION (IMPORTANT)
This product is a mixed-brand pivot solution.
It combines:
• QS components (structural compatibility)
• CISA components (locking and security performance)
👉 This is not a mismatch — it is a practical combination used to achieve the best overall performance.
KEY FEATURES
Brand: Mixed Solution (QS + CISA)
Model: QS5504 Lock Set
Function: Pivot Lock Set
Lock Type: Rollerbolt & Deadbolt
Door Type: Pivot Door
Maximum Door Weight: 250kg
Application: Heavy Duty
Material: Stainless Steel
Finish: Stainless Steel (SS)
COMPATIBLE OPTIONS
This lock set can be used with:
• Floor springs (QS899V recommended)
• Heavy duty pivot sets (QS5504)
• Euro profile cylinders
• Stainless steel pull handles with escutcheons
⚠️ PIVOT SET REQUIREMENT (VERY IMPORTANT)
This lock set does NOT carry door weight.
Recommended:
• Heavy doors → QS5504 Pivot Set (up to ±250kg)
👉 Using the incorrect pivot will result in failure.
⚠️ FLOOR SPRING REQUIREMENT (CRITICAL)
A floor spring is REQUIRED.
Recommended:
• Heavy doors → QS899V Floor Spring
👉 Without a floor spring, the door will not operate.
HOW TO IDENTIFY A HEAVY DOOR
| Door Type | Size (mm) | Weight | Recommendation |
|---|---|---|---|
| Standard | 2100 × 900 | 40–70kg | Not suitable |
| Medium | 2400 × 1000 | 70–120kg | Borderline |
| Large | 2600 × 1200 | 120–180kg | Suitable |
| Oversized | 2800mm+ | 180kg+ | Ideal |
WHAT TO LOOK OUT FOR
This lock is recommended if:
• Door exceeds 1000mm width
• Door exceeds 2400mm height
• Solid timber door
• High traffic use
• Feature entrance door
👉 This is a heavy duty application
BRAND COMPARISON – QS vs CISA vs DORMA
| Brand | Strength | Best Use |
|---|---|---|
| QS | Heavy duty + value | Structural components |
| CISA | Security + cylinders | Locking systems |
| Dorma | Premium | Architectural |
COMPLETE PIVOT DOOR SYSTEM (RECOMMENDED)
| Component | Example |
|---|---|
| Floor Spring | QS899V |
| Pivot Set | QS5504 |
| Lock Set | QS5504 Mixed Set |
| Cylinder | Euro Cylinder |
| Handles | Stainless Steel Pull Handles |
WHAT'S INCLUDED
• Lock components
• Rollerbolt & deadbolt
• Fixings
⚠️ Cylinder may vary
⚠️ Pivot set and floor spring NOT included
